760308101303
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 760308101303 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 760308101303 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 760308101303 |
|---|---|
| Manufacturer | Wurth Electronics |
| Description | RX 1 COIL 1 LAYER 47UH 1.5A |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 50 pcs | 100 pcs | 250 pcs | 384 pcs |
|---|---|---|---|---|---|
| $4.029 | $3.807 | $3.222 | $2.783 | $2.343 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | 760308101303 | Manufacturer | Wurth Electronics |
|---|---|---|---|
| Description | RX 1 COIL 1 LAYER 47UH 1.5A | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 13350 pcs | Data sheet | 760308101303 Drawing |
| Category | Inductors, Coils, Chokes | Type | 1 Coil, 1 Layer |
| Tolerance | ±10% | Size / Dimension | 1.02" L x 1.02" W x 0.05" H (26.0mm x 26.0mm x 1.3mm) |
| Series | WE-WPCC | Q @ Freq | 25 @ 125kHz |
| Other Names | 732-6207 | Operating Temperature | -20°C ~ 105°C |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 10 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Inductance | 47µH |
| Function | Receiver | Frequency - Self Resonant | 8MHz |
| Detailed Description | 1 Coil, 1 Layer 47µH Wireless Charging Coil Receiver 460 mOhm | DC Resistance (DCR) | 460 mOhm |
| Current Rating | 1.5A | Current - Saturation | 3A |
