760308101217
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 760308101217 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 760308101217 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 760308101217 |
|---|---|
| Manufacturer | Wurth Electronics |
| Description | RX 1 COIL 1 LAYER 24.2UH 400MA |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 60 pcs | 120 pcs | |
|---|---|---|---|---|---|
| $2.944 | $2.807 | $2.591 | $2.355 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 760308101217 | Manufacturer | Wurth Electronics |
|---|---|---|---|
| Description | RX 1 COIL 1 LAYER 24.2UH 400MA | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 15572 pcs | Data sheet | 760308101217 Drawing |
| Category | Inductors, Coils, Chokes | Type | 1 Coil, 1 Layer |
| Tolerance | ±10% | Size / Dimension | 0.41" Dia x 0.07" H (10.3mm x 1.9mm) |
| Series | WE-WPCC | Q @ Freq | 13 @ 125kHz |
| Other Names | 732-9674 | Operating Temperature | -20°C ~ 105°C |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 10 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Inductance | 24.2µH |
| Function | Receiver | Frequency - Self Resonant | 14.5MHz |
| Detailed Description | 1 Coil, 1 Layer 24.2µH Wireless Charging Coil Receiver 1.4 Ohm Max | DC Resistance (DCR) | 1.4 Ohm Max |
| Current Rating | 400mA | Current - Saturation | 1A |
