760308102144
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 760308102144 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 760308102144 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 760308102144 |
|---|---|
| Manufacturer | Wurth Electronics |
| Description | WE-WPCC WIRELESS POWER CHARGING |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 50 pcs | 100 pcs | 250 pcs | 500 pcs |
|---|---|---|---|---|---|
| $7.584 | $7.079 | $6.321 | $5.563 | $5.057 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | 760308102144 | Manufacturer | Wurth Electronics |
|---|---|---|---|
| Description | WE-WPCC WIRELESS POWER CHARGING | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 6584 pcs | Data sheet | 760308102144 Drawing |
| Category | Inductors, Coils, Chokes | Type | 1 Coil, 2 Layer |
| Tolerance | ±10% | Size / Dimension | 2.10" L x 2.10" W x 0.28" H (53.30mm x 53.30mm x 7.00mm) |
| Series | WE-WPCC | Q @ Freq | 220 @ 125kHz |
| Other Names | 732-11537 | Operating Temperature | -20°C ~ 105°C |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 10 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Inductance | 19.5µH |
| Function | Transmitter | Frequency - Self Resonant | 5MHz |
| Detailed Description | 1 Coil, 2 Layer 19.5µH Wireless Charging Coil Transmitter 45 mOhm Max | DC Resistance (DCR) | 45 mOhm Max |
| Current Rating | 9.5A | Current - Saturation | 20A |
