760308102306
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 760308102306 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 760308102306 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 760308102306 |
|---|---|
| Manufacturer | Wurth Electronics |
| Description | WE-WPCC WIRELESS POWER CHARGING |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 100 pcs | |||
|---|---|---|---|---|---|
| $6.056 | $5.229 | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | 760308102306 | Manufacturer | Wurth Electronics |
|---|---|---|---|
| Description | WE-WPCC WIRELESS POWER CHARGING | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 6974 pcs | Data sheet | 760308102306 Drawing |
| Category | Inductors, Coils, Chokes | Type | 2 Coil, 1 Layer |
| Tolerance | ±10% | Size / Dimension | 1.73" L x 1.73" W x 0.03" H (44.0mm x 44.0mm x 0.75mm) |
| Series | WE-WPCC | Q @ Freq | 19 @ 125kHz, 47 @ 125kHz |
| Other Names | 732-10831 | Operating Temperature | -20°C ~ 105°C |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 10 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Inductance | 8µH, 1.4µH |
| Function | Receiver | Frequency - Self Resonant | 17.5MHz, 19MHz |
| Detailed Description | 2 Coil, 1 Layer 8µH, 1.4µH Wireless Charging Coil Receiver 400 mOhm Max, 100 mOhm Max | DC Resistance (DCR) | 400 mOhm Max, 100 mOhm Max |
| Current Rating | 2A, 5A | Current - Saturation | 5A, 5A |
