760308100143
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 760308100143 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 760308100143 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 760308100143 |
|---|---|
| Manufacturer | Wurth Electronics |
| Description | TX 1 COIL 1 LAYER 6UH 12A |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 100 pcs | 500 pcs | |
|---|---|---|---|---|---|
| $7.334 | $6.991 | $6.428 | $5.846 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 760308100143 | Manufacturer | Wurth Electronics |
|---|---|---|---|
| Description | TX 1 COIL 1 LAYER 6UH 12A | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 6724 pcs | Data sheet | 760308100143 Drawing |
| Category | Inductors, Coils, Chokes | Type | 1 Coil, 1 Layer |
| Tolerance | ±10% | Size / Dimension | 1.97" Dia x 0.26" H (50.0mm x 6.7mm) |
| Series | WE-WPCC | Q @ Freq | 180 @ 125kHz |
| Other Names | 732-9671 | Operating Temperature | -20°C ~ 105°C |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 10 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Inductance | 6µH |
| Function | Transmitter | Frequency - Self Resonant | 16MHz |
| Detailed Description | 1 Coil, 1 Layer 6µH Wireless Charging Coil Transmitter 18 mOhm Max | DC Resistance (DCR) | 18 mOhm Max |
| Current Rating | 12A | Current - Saturation | 24A |
