760308101103
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 760308101103 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 760308101103 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 760308101103 |
|---|---|
| Manufacturer | Wurth Electronics |
| Description | TX 1 COIL 1 LAYER 6.5UH 3A |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 50 pcs | 84 pcs | 168 pcs | 336 pcs |
|---|---|---|---|---|---|
| $4.005 | $3.785 | $3.203 | $2.766 | $2.329 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | 760308101103 | Manufacturer | Wurth Electronics |
|---|---|---|---|
| Description | TX 1 COIL 1 LAYER 6.5UH 3A | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 13848 pcs | Data sheet | 760308101103 Drawing |
| Category | Inductors, Coils, Chokes | Type | 1 Coil, 1 Layer |
| Tolerance | ±10% | Size / Dimension | 1.18" L x 1.18" W x 0.07" H (30.0mm x 30.0mm x 1.9mm) |
| Series | WE-WPCC | Q @ Freq | 35 @ 125kHz |
| Other Names | 732-5673 | Operating Temperature | -20°C ~ 105°C |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 10 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Inductance | 6.5µH |
| Function | Transmitter | Frequency - Self Resonant | 20MHz |
| Detailed Description | 1 Coil, 1 Layer 6.5µH Wireless Charging Coil Transmitter 180 mOhm Max | DC Resistance (DCR) | 180 mOhm Max |
| Current Rating | 3A | Current - Saturation | 8A |
