760308103211
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 760308103211 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 760308103211 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 760308103211 |
|---|---|
| Manufacturer | Wurth Electronics |
| Description | RX 1 COIL 1 LAYER 7.3UH 2.5A |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 24 pcs | 48 pcs | 96 pcs |
|---|---|---|---|---|---|
| $2.948 | $2.73 | $2.482 | $2.256 | $2.051 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | 760308103211 | Manufacturer | Wurth Electronics |
|---|---|---|---|
| Description | RX 1 COIL 1 LAYER 7.3UH 2.5A | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 19252 pcs | Data sheet | 760308103211 Drawing |
| Category | Inductors, Coils, Chokes | Type | 1 Coil, 1 Layer |
| Tolerance | ±10% | Size / Dimension | 1.81" L x 1.42" W x 0.03" H (46.0mm x 36.0mm x 0.7mm) |
| Series | WE-WPCC | Q @ Freq | 28 @ 125kHz |
| Other Names | 732-8237 | Operating Temperature | -20°C ~ 105°C |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 10 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Inductance | 7.3µH |
| Function | Receiver | Frequency - Self Resonant | 12.7MHz |
| Detailed Description | 1 Coil, 1 Layer 7.3µH Wireless Charging Coil Receiver 200 mOhm Max | DC Resistance (DCR) | 200 mOhm Max |
| Current Rating | 2.5A | Current - Saturation | 5A |
