760308104113
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 760308104113 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 760308104113 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 760308104113 |
|---|---|
| Manufacturer | Wurth Electronics |
| Description | TX 1 COIL 1 LAYER 12UH 7A |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 50 pcs | 100 pcs | 500 pcs |
|---|---|---|---|---|---|
| $5.376 | $4.923 | $4.651 | $4.379 | $4.135 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | 760308104113 | Manufacturer | Wurth Electronics |
|---|---|---|---|
| Description | TX 1 COIL 1 LAYER 12UH 7A | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 9495 pcs | Data sheet | 760308104113 DrawingWireless Power Transfer Flyer |
| Category | Inductors, Coils, Chokes | Type | 1 Coil, 1 Layer |
| Tolerance | ±10% | Size / Dimension | 2.34" L x 2.05" W x 0.15" H (59.5mm x 52.0mm x 4.0mm) |
| Series | WE-WPCC | Q @ Freq | 120 @ 125kHz |
| Other Names | 732-5717 | Operating Temperature | -20°C ~ 105°C |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 8 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Inductance | 12µH |
| Function | Transmitter | Frequency - Self Resonant | 16MHz |
| Detailed Description | 1 Coil, 1 Layer 12µH Wireless Charging Coil Transmitter 72 mOhm Max | DC Resistance (DCR) | 72 mOhm Max |
| Current Rating | 7A | Current - Saturation | 12A |
