1750H
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 1750H with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 1750H with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 1750H |
|---|---|
| Manufacturer | Hammond Manufacturing |
| Description | TRANSFORMER TUBE GUITAR AMP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $15.163 | $13.38 | $12.934 | $11.596 | $11.15 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | 1750H | Manufacturer | Hammond Manufacturing |
|---|---|---|---|
| Description | TRANSFORMER TUBE GUITAR AMP | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 2725 pcs | Data sheet | 1750,1760 Series Spec.1750 Series Catalog Page1750H Drawing |
| Category | Transformers | Weight | 0.625 lb (283.5g) |
| Voltage - Isolation | - | Turns Ratio - Primary:Secondary | 28.72:1 |
| Transformer Type | Push-Pull Audiophile, Ultra-Linear - Tube Output | Termination Style | Wire Leads |
| Size / Dimension | 3.710" L x 2.400" W (94.23mm x 60.96mm) | Series | 1750 |
| Return Loss | - | Power Level | 20W |
| Packaging | Bulk | Other Names | 1750H-ND HM4562 |
| Operating Temperature | - | Mounting Type | Chassis Mount |
| Manufacturer Standard Lead Time | 4 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insertion Loss | - | Impedance - Secondary (Ohms) | 8 |
| Impedance - Primary (Ohms) | 6.6kCT | Height - Seated (Max) | 2.371" (60.22mm) |
| Frequency Response | ±1dB | Frequency Range | 70Hz ~ 15kHz |
| DC Resistance (DCR) - Secondary | 470 mOhm | DC Resistance (DCR) - Primary | 428 Ohm |
| Approvals | - |
