1750P
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 1750P with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 1750P with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 1750P |
|---|---|
| Manufacturer | Hammond Manufacturing |
| Description | TRANSFORMER TUBE GUITAR AMP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $32.917 | $31.82 | $29.626 | $27.431 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 1750P | Manufacturer | Hammond Manufacturing |
|---|---|---|---|
| Description | TRANSFORMER TUBE GUITAR AMP | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 1141 pcs | Data sheet | 1750,1760 Series Spec.1750 Series Catalog Page1750P Drawing |
| Category | Transformers | Weight | 0.625 lb (283.5g) |
| Voltage - Isolation | - | Turns Ratio - Primary:Secondary | 14.24:1 |
| Transformer Type | Push-Pull Audiophile, Ultra-Linear - Tube Output | Termination Style | Solder Lug |
| Size / Dimension | 3.750" L x 3.090" W (95.25mm x 78.49mm) | Series | 1750 |
| Return Loss | - | Power Level | 50W |
| Packaging | Bulk | Other Names | 1750P-ND HM4571 |
| Operating Temperature | - | Mounting Type | Chassis Mount |
| Manufacturer Standard Lead Time | 4 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insertion Loss | - | Impedance - Secondary (Ohms) | 2, 4, 8, 16 |
| Impedance - Primary (Ohms) | 3.4kCT | Height - Seated (Max) | 3.188" (80.98mm) |
| Frequency Response | ±1dB | Frequency Range | 50Hz ~ 12kHz |
| DC Resistance (DCR) - Secondary | 120 mOhm, 150 mOhm, 210 mOhm | DC Resistance (DCR) - Primary | 41.3 Ohm, 40.5 Ohm, 81.8 Ohm |
| Approvals | - |
