1750NA
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 1750NA with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 1750NA with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 1750NA |
|---|---|
| Manufacturer | Hammond Manufacturing |
| Description | TRANSFORMER TUBE GUITAR AMP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $16.142 | $15.604 | $14.528 | $13.452 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 1750NA | Manufacturer | Hammond Manufacturing |
|---|---|---|---|
| Description | TRANSFORMER TUBE GUITAR AMP | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 2752 pcs | Data sheet | 1750,1760 Series Spec.1750NA Drawing |
| Category | Transformers | Weight | - |
| Voltage - Isolation | 2500V @ 1 Second | Turns Ratio - Primary:Secondary | - |
| Termination Style | Solder Lug | Size / Dimension | 3.000" L x 2.465" W (76.20mm x 62.61mm) |
| Series | 1750 | Return Loss | - |
| Power Level | 30W | Packaging | Bulk |
| Other Names | 1750NA-ND HM4569 |
Operating Temperature | - |
| Mounting Type | Chassis Mount | Manufacturer Standard Lead Time | 4 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insertion Loss | - |
| Impedance - Secondary (Ohms) | 8, 16 | Impedance - Primary (Ohms) | 6kCT |
| Height - Seated (Max) | 2.525" (64.14mm) | Frequency Response | ±1dB |
| Frequency Range | 50Hz ~ 12kHz | DC Resistance (DCR) - Secondary | 300 mOhm, 580 mOhm, 820 mOhm |
| DC Resistance (DCR) - Primary | 73.2 Ohm, 74.41 Ohm, 147.4 Ohm | Approvals | - |
