1750D
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 1750D with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 1750D with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 1750D |
|---|---|
| Manufacturer | Hammond Manufacturing |
| Description | TRANSFORMER TUBE GUITAR AMP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $31.682 | $30.625 | $28.513 | $26.401 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 1750D | Manufacturer | Hammond Manufacturing |
|---|---|---|---|
| Description | TRANSFORMER TUBE GUITAR AMP | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 1474 pcs | Data sheet | 1750,1760 Series Spec.1750D |
| Category | Transformers | Weight | - |
| Voltage - Isolation | 2000V @ 1 Second | Turns Ratio - Primary:Secondary | - |
| Termination Style | Wire Leads | Size / Dimension | 4.050" L x 3.715" W (102.87mm x 94.36mm) |
| Series | 1750 | Return Loss | - |
| Power Level | 100W | Packaging | Bulk |
| Other Names | 1750D-ND HM4558 |
Operating Temperature | - |
| Mounting Type | Chassis Mount | Moisture Sensitivity Level (MSL) | Not Applicable |
| Manufacturer Standard Lead Time | 4 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insertion Loss | - | Impedance - Secondary (Ohms) | 4, 8, 16 |
| Impedance - Primary (Ohms) | 2.35kCT/25m | Height - Seated (Max) | 3.563" (90.50mm) |
| Frequency Response | ±1dB | Frequency Range | 70Hz ~ 15kHz |
| DC Resistance (DCR) - Secondary | 300 mOhm, 690 mOhm, 860 mOhm | DC Resistance (DCR) - Primary | 33.09 Ohm, 34.82 Ohm, 370 mOhm |
| Approvals | - |
