1750G
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 1750G with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 1750G with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 1750G |
|---|---|
| Manufacturer | Hammond Manufacturing |
| Description | TRANSFORMER TUBE GUITAR AMP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $50.198 | $48.524 | $45.178 | $41.831 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 1750G | Manufacturer | Hammond Manufacturing |
|---|---|---|---|
| Description | TRANSFORMER TUBE GUITAR AMP | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 814 pcs | Data sheet | 1750,1760 Series Spec.1750G Drawing1750 Series Catalog Page |
| Category | Transformers | Weight | 0.625 lb (283.5g) |
| Voltage - Isolation | - | Turns Ratio - Primary:Secondary | 14.21:1 |
| Transformer Type | Push-Pull Audiophile, Ultra-Linear - Tube Output | Termination Style | Wire Leads |
| Size / Dimension | 3.750" L x 3.320" W (95.25mm x 84.33mm) | Series | 1750 |
| Return Loss | - | Power Level | 50W |
| Packaging | Bulk | Other Names | 1750G-ND HM4561 |
| Operating Temperature | - | Mounting Type | Chassis Mount |
| Moisture Sensitivity Level (MSL) | Not Applicable | Manufacturer Standard Lead Time | 4 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insertion Loss | - |
| Impedance - Secondary (Ohms) | 4, 8, 16 | Impedance - Primary (Ohms) | 3.8kCT |
| Height - Seated (Max) | 3.873" (98.37mm) | Frequency Response | ±1dB |
| Frequency Range | 50Hz ~ 12kHz | DC Resistance (DCR) - Secondary | 250 mOhm |
| DC Resistance (DCR) - Primary | 95.61 Ohm | Approvals | - |
