Home > Products > Transformers > Switching Converter, SMPS Transformers > ECO2023SEO-D01H016

ECO2023SEO-D01H016

ECO2023SEO-D01H016

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy ECO2023SEO-D01H016 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	ECO2023SEO-D01H016
Manufacturer	TDK Corporation
Description	INDUCTOR/XFRMR
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 19784 pcs
Reference Price (In US Dollars)	30 pcs
Reference Price (In US Dollars)	$1.836

Product parameter
Data sheet

Product parameter

Part Number	ECO2023SEO-D01H016	Manufacturer	TDK Corporation
Description	INDUCTOR/XFRMR	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	19784 pcs	Data sheet	ECO Series
Category	Transformers	Voltage - Primary	85 ~ 276V
Voltage - Isolation	3000Vrms	Voltage - Auxiliary	12V @ 1.3A
Type	For AC/DC Converters	Size / Dimension	0.925" L x 1.161" W (23.50mm x 29.50mm)
Series	ECO	Packaging	Bulk
Other Names	445-16072	Operating Temperature	-30°C ~ 120°C
Mounting Type	Through Hole	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Manufacturer Standard Lead Time	10 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Intended Chipset	-	Inductance @ Frequency	489µH @ 10kHz
Height - Seated (Max)	0.787" (20.00mm)	Frequency	100kHz
Footprint	0.925" L x 1.161" W (23.50mm x 29.50mm)	Chipset Manufacturer	-
Applications	Flyback Converters
