1461680001
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 1461680001 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 1461680001 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 1461680001 |
|---|---|
| Manufacturer | Affinity Medical Technologies - a Molex company |
| Description | RF ANT 1.575GHZ CER PATCH SLD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 50 pcs | 100 pcs | 250 pcs |
|---|---|---|---|---|---|
| $0.82 | $0.741 | $0.662 | $0.596 | $0.529 | |
| 500 pcs | 1000 pcs | 2500 pcs | 5000 pcs | ||
| $0.463 | $0.384 | $0.357 | $0.344 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 1461680001 | Manufacturer | Affinity Medical Technologies - a Molex company |
|---|---|---|---|
| Description | RF ANT 1.575GHZ CER PATCH SLD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 56854 pcs | Data sheet | 146168 DrawingGNSS Antennas Overview |
| Category | RF/IF and RFID | VSWR | - |
| Termination | Solder | Series | 146168 |
| Return Loss | - | Power - Max | 2W |
| Packaging | Bulk | Other Names | 146168-0001 WM16030 |
| Number of Bands | 1 | Mounting Type | Surface Mount |
| Manufacturer Standard Lead Time | 10 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Ingress Protection | - | Height (Max) | 0.157" (4.00mm) |
| Gain | 5.5dBi | Frequency Range | 1.572GHz ~ 1.578GHz |
| Frequency Group | UHF (1 GHz ~ 2 GHz) | Frequency (Center/Band) | 1.575GHz |
| Features | - | Detailed Description | 1.575GHz GNSS, GPS Ceramic Patch RF Antenna 1.572GHz ~ 1.578GHz 5.5dBi Solder Surface Mount |
| Applications | GNSS, GPS | Antenna Type | Ceramic Patch |
