1461794001
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 1461794001 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 1461794001 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 1461794001 |
|---|---|
| Manufacturer | Affinity Medical Technologies - a Molex company |
| Description | RX 2 COIL 1 LAYER 8.9UH |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 100 pcs | 500 pcs | 1000 pcs |
|---|---|---|---|---|---|
| $4.028 | $3.725 | $3.02 | $2.819 | $2.678 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | 1461794001 | Manufacturer | Affinity Medical Technologies - a Molex company |
|---|---|---|---|
| Description | RX 2 COIL 1 LAYER 8.9UH | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 11672 pcs | Data sheet | PowerLife™ Power Coils Brochure1461794001 Drawing1461794001 Appl Spec1461794001 Prod Spec |
| Category | Inductors, Coils, Chokes | Type | 2 Coil, 1 Layer |
| Tolerance | ±2% | Size / Dimension | 2.579" L x 1.906" W x 0.020" H (65.50mm x 48.40mm x 0.52mm) |
| Series | NuCurrent, PowerLife, 146179 | Q @ Freq | 25 @ 200kHz |
| Other Names | 146179-4001 WM15002 |
Operating Temperature | - |
| Manufacturer Standard Lead Time | 8 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance | 8.9µH | Function | Receiver |
| Frequency - Self Resonant | - | Detailed Description | 2 Coil, 1 Layer 8.9µH Wireless Charging Coil Receiver 350 mOhm |
| DC Resistance (DCR) | 350 mOhm | Current Rating | - |
| Current - Saturation | - |
