AZ-1000
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy AZ-1000 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy AZ-1000 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | AZ-1000 |
|---|---|
| Manufacturer | Talema |
| Description | CURR SENSE XFMR 1000:1 50A SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 560 pcs | ||||
|---|---|---|---|---|---|
| $1.568 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | AZ-1000 | Manufacturer | Talema |
|---|---|---|---|
| Description | CURR SENSE XFMR 1000:1 50A SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 23182 pcs | Data sheet | AZ Series |
| Category | Transformers | Weight | - |
| Type | Non-Invasive (Solid Core) | Turns Ratio - Primary:Secondary | 1000:1 |
| Termination Style | Wire Leads | Size / Dimension | 0.748" Dia (19.00mm) |
| Series | AZ | Ratings | - |
| Packaging | Tray | Other Names | 1295-1138 |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 18 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Height - Seated (Max) | 0.453" (11.50mm) | Frequency Range | 50Hz ~ 60Hz |
| Energy Time (E.T.) | - | Detailed Description | 50A 1000:1 Current Sense Transformer 50Hz ~ 60Hz 72 Ohm Primary Surface Mount |
| DC Resistance (DCR) | 72 Ohm Primary | Current Ratio | - |
| Current Rating | 50A |
