CSE184L
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy CSE184L with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy CSE184L with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | CSE184L |
|---|---|
| Manufacturer | Triad Magnetics |
| Description | CURR SENSE XFMR 1A T/H |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $1.177 | $0.954 | $0.771 | $0.722 | $0.69 | |
| 250 pcs | 500 pcs | 1000 pcs | 5000 pcs | ||
| $0.67 | $0.649 | $0.629 | $0.578 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | CSE184L | Manufacturer | Triad Magnetics |
|---|---|---|---|
| Description | CURR SENSE XFMR 1A T/H | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 61012 pcs | Data sheet | CSE184L Datasheet |
| Category | Transformers | Weight | - |
| Type | Invasive | Termination Style | PC Pin |
| Size / Dimension | 0.846" L x 0.945" W (21.50mm x 24.00mm) | Series | - |
| Ratings | - | Packaging | Bulk |
| Other Names | 237-2082 | Mounting Type | Through Hole |
| Manufacturer Standard Lead Time | 16 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Height - Seated (Max) | 0.709" (18.00mm) | Frequency Range | 50Hz ~ 400Hz |
| Energy Time (E.T.) | - | Detailed Description | 1A Current Sense Transformer 50Hz ~ 400Hz 125 mOhm Primary, 23 Ohm Secondary Through Hole |
| DC Resistance (DCR) | 125 mOhm Primary, 23 Ohm Secondary | Current Ratio | - |
| Current Rating | 1A |
