Home > Products > Switches > Rocker Switches > SW3822/U

SW3822/U

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SW3822/U with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	SW3822/U
Manufacturer	NKK Switches
Description	SWITCH ROCKER DPDT 30A 125V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	100 pcs	250 pcs	500 pcs
~~In Stock~~ 6796 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	25 pcs	50 pcs
	$8.052	$7.416	$7.204	$6.992
	$6.78	$6.145	$5.721

Product parameter
Data sheet

Product parameter

Part Number	SW3822/U	Manufacturer	NKK Switches
Description	SWITCH ROCKER DPDT 30A 125V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	6796 pcs	Data sheet	SW Series Medium Cap Rocker Datasheet
Category	Switches	Voltage Rating - DC	30V
Voltage Rating - AC	125V	Termination Style	Screw Terminal
Switch Function	On-On	Series	SW
Panel Cutout Dimensions	-	Packaging	Bulk
Other Names	360-2931 SW3822/U-ND SW3822/U-RO SW3822/U-RO-ND SW3822U	Operating Temperature	-10°C ~ 70°C
Mounting Type	Panel Mount, Flange	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Mechanical Life	50,000 Cycles	Manufacturer Standard Lead Time	5 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Ingress Protection	-
Illumination Voltage (Nominal)	-	Illumination Type, Color	-
Features	-	Electrical Life	25,000 Cycles
Detailed Description	Rocker Switch DPDT 30A (AC/DC) 125V Panel Mount, Flange	Current Rating	30A (AC/DC)
Color - Actuator/Cap	White	Circuit	DPDT
Actuator Type	Concave (Standard V)	Actuator Marking	No Marking
