744284101
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 744284101 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 744284101 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 744284101 |
|---|---|
| Manufacturer | Wurth Electronics |
| Description | CMC 100UH 1A 2LN 40 KOHM SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 250 pcs | 500 pcs | |||
|---|---|---|---|---|---|
| $1.027 | $0.945 | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | 744284101 | Manufacturer | Wurth Electronics |
|---|---|---|---|
| Description | CMC 100UH 1A 2LN 40 KOHM SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 34199 pcs | Data sheet | 744284101 |
| Category | Filters | Voltage Rating - DC | 80V |
| Voltage Rating - AC | - | Size / Dimension | 0.492" L x 0.492" W (12.50mm x 12.50mm) |
| Series | WE-SCC | Ratings | - |
| Packaging | Tape & Reel (TR) | Package / Case | Horizontal, 4 PC Pad |
| Other Names | 732-2970-2 | Operating Temperature | -40°C ~ 125°C |
| Number of Lines | 2 | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 14 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Inductance @ Frequency | 100µH @ 100kHz |
| Impedance @ Frequency | 40 kOhms @ 4MHz | Height (Max) | 0.413" (10.50mm) |
| Filter Type | Signal Line | Features | - |
| Detailed Description | 100µH @ 100kHz 2 Line Common Mode Choke Surface Mount 40 kOhms @ 4MHz 1A DCR 280 mOhm | DC Resistance (DCR) (Max) | 280 mOhm |
| Current Rating (Max) | 1A | Approvals | - |
