744273501
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 744273501 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 744273501 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 744273501 |
|---|---|
| Manufacturer | Wurth Electronics |
| Description | CMC 5UH 5A 2LN 500 OHM SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 50 pcs | 100 pcs | 500 pcs |
|---|---|---|---|---|---|
| $1.197 | $1.11 | $1.002 | $0.967 | $0.895 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | 744273501 | Manufacturer | Wurth Electronics |
|---|---|---|---|
| Description | CMC 5UH 5A 2LN 500 OHM SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 41776 pcs | Data sheet | 744273501 |
| Category | Filters | Voltage Rating - DC | 80V |
| Voltage Rating - AC | - | Size / Dimension | 0.374" L x 0.327" W (9.50mm x 8.30mm) |
| Series | WE-SL5 | Ratings | - |
| Packaging | Cut Tape (CT) | Package / Case | Horizontal, 4 PC Pad |
| Other Names | 732-2214-1 | Operating Temperature | -40°C ~ 125°C |
| Number of Lines | 2 | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 10 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Inductance @ Frequency | 5µH @ 100kHz |
| Impedance @ Frequency | 500 Ohms @ 130MHz | Height (Max) | 0.209" (5.30mm) |
| Filter Type | Signal Line | Features | - |
| Detailed Description | 5µH @ 100kHz 2 Line Common Mode Choke Surface Mount 500 Ohms @ 130MHz 5A DCR 5.5 mOhm | DC Resistance (DCR) (Max) | 5.5 mOhm |
| Current Rating (Max) | 5A | Approvals | - |
