Home > Products > Transformers > Switching Converter, SMPS Transformers > ECO2425SLD-D01H017

ECO2425SLD-D01H017

ECO2425SLD-D01H017

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy ECO2425SLD-D01H017 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	ECO2425SLD-D01H017
Manufacturer	TDK Corporation
Description	INDUCTOR/XFRMR
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	100 pcs	250 pcs	500 pcs	1000 pcs
~~In Stock~~ 23833 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	25 pcs	50 pcs
	$2.472	$1.879	$1.83	$1.681
	$1.582	$1.533	$1.483	$1.434

Product parameter
Data sheet

Product parameter

Part Number	ECO2425SLD-D01H017	Manufacturer	TDK Corporation
Description	INDUCTOR/XFRMR	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	23833 pcs	Data sheet	ECO Series
Category	Transformers	Voltage - Primary	100 ~ 370V
Voltage - Isolation	3000Vrms	Voltage - Auxiliary	12.7V @ 2.33A
Type	For AC/DC Converters	Size / Dimension	1.024" L x 1.181" W (26.00mm x 30.00mm)
Series	ECO	Packaging	Bulk
Other Names	445-16088	Operating Temperature	-30°C ~ 120°C
Mounting Type	Through Hole	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Manufacturer Standard Lead Time	10 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Intended Chipset	-	Inductance @ Frequency	722µH @ 10kHz
Height - Seated (Max)	0.787" (20.00mm)	Frequency	-
Footprint	1.024" L x 1.181" W (26.00mm x 30.00mm)	Chipset Manufacturer	-
Applications	Flyback Converters
