CPFC805NP-100M05
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy CPFC805NP-100M05 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy CPFC805NP-100M05 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | CPFC805NP-100M05 |
|---|---|
| Manufacturer | Sumida Corporation |
| Description | CMC 4.5A 2LN 500 OHM SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1000 pcs | 3000 pcs | 5000 pcs | 10000 pcs | |
|---|---|---|---|---|---|
| $0.372 | $0.36 | $0.348 | $0.336 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | CPFC805NP-100M05 | Manufacturer | Sumida Corporation |
|---|---|---|---|
| Description | CMC 4.5A 2LN 500 OHM SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 64466 pcs | Data sheet | CPFC805 |
| Category | Filters | Voltage Rating - DC | - |
| Voltage Rating - AC | - | Size / Dimension | 0.311" L x 0.295" W (7.90mm x 7.50mm) |
| Series | CPFC | Ratings | - |
| Packaging | Tape & Reel (TR) | Package / Case | - |
| Other Names | 308-1562-2 CPFC805NP100M05 |
Operating Temperature | - |
| Number of Lines | 2 | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 14 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Impedance @ Frequency | 500 Ohms @ 100MHz |
| Height (Max) | 0.189" (4.80mm) | Filter Type | Power Line |
| Features | - | Detailed Description | 2 Line Common Mode Choke Surface Mount 500 Ohms @ 100MHz 4.5A DCR 15 mOhm |
| DC Resistance (DCR) (Max) | 15 mOhm | Current Rating (Max) | 4.5A |
| Approvals | - |
