RDK-142
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy RDK-142 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy RDK-142 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | RDK-142 |
|---|---|
| Manufacturer | Power Integrations |
| Description | KIT REF DESIGN TOP HX FOR TOP258 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | RDK-142 | Manufacturer | Power Integrations |
|---|---|---|---|
| Description | KIT REF DESIGN TOP HX FOR TOP258 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 5963 pcs | Data sheet | Reference Design 142 |
| Category | Development Boards, Kits, Programmers | Voltage - Output | 5V, 12V |
| Voltage - Input | 90 ~ 265 VAC | Utilized IC / Part | TOP258 |
| Supplied Contents | Board(s) | Series | TOPSwitch®-HX |
| Regulator Topology | Flyback | Power - Output | 35W |
| Outputs and Type | 2, Non-Isolated | Other Names | 596-1193 RDK142 |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Main Purpose | AC/DC, Primary Side |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Frequency - Switching | 30kHz |
| Detailed Description | TOP258 TOPSwitch®-HX AC/DC, Primary Side 2, Non-Isolated Outputs Evaluation Board | Current - Output | 2.2A, 2A |
| Board Type | Fully Populated |
