RDK-239
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy RDK-239 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy RDK-239 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | RDK-239 |
|---|---|
| Manufacturer | Power Integrations |
| Description | BOARD EVAL FOR LCS702HG |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | RDK-239 | Manufacturer | Power Integrations |
|---|---|---|---|
| Description | BOARD EVAL FOR LCS702HG | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Quantity Available | 4907 pcs | Data sheet | LCS700-708150 W LLC Converter Ref Design Report |
| Category | Development Boards, Kits, Programmers | Voltage - Output | 24V |
| Voltage - Input | 300 V ~ 420 V | Utilized IC / Part | LCS702HG |
| Supplied Contents | Board(s) | Series | HiperLCS™ |
| Regulator Topology | Resonant | Power - Output | 150W |
| Outputs and Type | 1, Isolated | Other Names | 596-1429 RDK239 |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Main Purpose | DC/DC, Step Down |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | Frequency - Switching | - |
| Detailed Description | LCS702HG HiperLCS™ DC/DC, Step Down 1, Isolated Outputs Evaluation Board | Current - Output | 6.25A |
| Board Type | Fully Populated |
