Home > Products > Connectors, Interconnects > Terminal Blocks - Wire to Board > 1862246

1862246

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 1862246 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	1862246
Manufacturer	Phoenix Contact
Description	PCB TERMINAL BLOCK 14POS 3.5MM
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	250 pcs	500 pcs	1000 pcs
~~In Stock~~ 29138 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	50 pcs	100 pcs
	$1.95	$1.898	$1.774	$1.632
	$1.508	$1.437	$1.348

Product parameter
Data sheet

Product parameter

Part Number	1862246	Manufacturer	Phoenix Contact
Description	PCB TERMINAL BLOCK 14POS 3.5MM	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	29138 pcs	Data sheet	1862246 Datasheet
Category	Connectors, Interconnects	Wire Termination	Screwless - Leg Spring, Push-In Spring
Wire Gauge	16-24 AWG	Voltage	300V
Torque - Screw	-	Series	COMBICON SPTAF EL
Screw Thread	-	Screw Material - Plating	-
Positions Per Level	14	Pitch	0.138" (3.50mm)
Packaging	Bulk	Other Names	277-12166 SPTAF 1/14-3,5-EL
Operating Temperature	-	Number of Levels	1
Mounting Type	Through Hole	Mating Orientation	45° (135°) Angle with Board
Manufacturer Standard Lead Time	7 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Housing Material	Polyamide (PA), Nylon	Features	Interlocking (Side)
Detailed Description	14 Position Wire to Board Terminal Block 45° (135°) Angle with Board 0.138" (3.50mm) Through Hole	Current	8A
Contact Material - Plating	-	Color	Green
Clamp Material - Plating	-
