Home > Products > Connectors, Interconnects > Terminal Blocks - Wire to Board > 1862233

1862233

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 1862233 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	1862233
Manufacturer	Phoenix Contact
Description	PCB TERMINAL BLOCK 13POS 3.5MM
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	250 pcs	500 pcs	1000 pcs
~~In Stock~~ 26694 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	50 pcs	100 pcs
	$1.752	$1.703	$1.592	$1.464
	$1.353	$1.289	$1.21

Product parameter
Data sheet

Product parameter

Part Number	1862233	Manufacturer	Phoenix Contact
Description	PCB TERMINAL BLOCK 13POS 3.5MM	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	26694 pcs	Data sheet	1862233 Datasheet
Category	Connectors, Interconnects	Wire Termination	Screwless - Leg Spring, Push-In Spring
Wire Gauge	16-24 AWG	Voltage	300V
Torque - Screw	-	Series	COMBICON SPTAF EL
Screw Thread	-	Screw Material - Plating	-
Positions Per Level	13	Pitch	0.138" (3.50mm)
Packaging	Bulk	Other Names	277-12165 SPTAF 1/13-3,5-EL
Operating Temperature	-	Number of Levels	1
Mounting Type	Through Hole	Mating Orientation	45° (135°) Angle with Board
Manufacturer Standard Lead Time	7 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Housing Material	Polyamide (PA), Nylon	Features	Interlocking (Side)
Detailed Description	13 Position Wire to Board Terminal Block 45° (135°) Angle with Board 0.138" (3.50mm) Through Hole	Current	8A
Contact Material - Plating	-	Color	Green
Clamp Material - Plating	-
