JAN1N5554US
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy JAN1N5554US with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy JAN1N5554US with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | JAN1N5554US |
|---|---|
| Manufacturer | Microsemi |
| Description | DIODE GEN PURP 1KV 5A D5B |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Reference Price (In US Dollars) | 100 pcs | ||||
|---|---|---|---|---|---|
| $4.828 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | JAN1N5554US | Manufacturer | Microsemi |
|---|---|---|---|
| Description | DIODE GEN PURP 1KV 5A D5B | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Quantity Available | 6317 pcs | Data sheet | 1N5550US thru 1N5554US |
| Category | Discrete Semiconductor Products | Voltage - Forward (Vf) (Max) @ If | 1.3V @ 9A |
| Voltage - DC Reverse (Vr) (Max) | 1000V | Supplier Device Package | D-5B |
| Speed | Standard Recovery >500ns, > 200mA (Io) | Series | Military, MIL-PRF-19500/420 |
| Reverse Recovery Time (trr) | 2µs | Packaging | Bulk |
| Package / Case | SQ-MELF, B | Other Names | 1086-15219 1086-15219-MIL |
| Operating Temperature - Junction | -65°C ~ 175°C | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 8 Weeks |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | Diode Type | Standard |
| Detailed Description | Diode Standard 1000V 5A Surface Mount D-5B | Current - Reverse Leakage @ Vr | 1µA @ 1000V |
| Current - Average Rectified (Io) | 5A | Capacitance @ Vr, F | - |
