APTGT600U170D4G
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy APTGT600U170D4G with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy APTGT600U170D4G with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | APTGT600U170D4G |
|---|---|
| Manufacturer | Microsemi |
| Description | IGBT TRENCH SGL SWITCH 1700V D4 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | ||
|---|---|---|---|---|---|
| $65.346 | $62.191 | $59.938 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | APTGT600U170D4G | Manufacturer | Microsemi |
|---|---|---|---|
| Description | IGBT TRENCH SGL SWITCH 1700V D4 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 645 pcs | Data sheet | Power Products CatalogAPTGT600U170D4G |
| Category | Discrete Semiconductor Products | Voltage - Collector Emitter Breakdown (Max) | 1700V |
| Vce(on) (Max) @ Vge, Ic | 2.4V @ 15V, 600A | Supplier Device Package | D4 |
| Series | - | Power - Max | 2900W |
| Package / Case | D4 | Operating Temperature | -40°C ~ 150°C (TJ) |
| NTC Thermistor | No | Mounting Type | Chassis Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 32 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Input Capacitance (Cies) @ Vce | 51nF @ 25V |
| Input | Standard | IGBT Type | Trench Field Stop |
| Detailed Description | IGBT Module Trench Field Stop Single 1700V 1100A 2900W Chassis Mount D4 | Current - Collector Cutoff (Max) | 1mA |
| Current - Collector (Ic) (Max) | 1100A | Configuration | Single |
