APTGT600A60G
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy APTGT600A60G with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy APTGT600A60G with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | APTGT600A60G |
|---|---|
| Manufacturer | Microsemi |
| Description | POWER MODULE IGBT 600V 600A SP6 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | ||
|---|---|---|---|---|---|
| $63.056 | $60.01 | $57.836 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | APTGT600A60G | Manufacturer | Microsemi |
|---|---|---|---|
| Description | POWER MODULE IGBT 600V 600A SP6 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 663 pcs | Data sheet | APTGT600A60GPower Products Catalog |
| Category | Discrete Semiconductor Products | Voltage - Collector Emitter Breakdown (Max) | 600V |
| Vce(on) (Max) @ Vge, Ic | 1.8V @ 15V, 600A | Supplier Device Package | SP6 |
| Series | - | Power - Max | 2300W |
| Package / Case | SP6 | Other Names | APTGT600A60GMI APTGT600A60GMI-ND |
| Operating Temperature | -40°C ~ 175°C (TJ) | NTC Thermistor | No |
| Mounting Type | Chassis Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 32 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Input Capacitance (Cies) @ Vce | 49nF @ 25V | Input | Standard |
| IGBT Type | Trench Field Stop | Detailed Description | IGBT Module Trench Field Stop Half Bridge 600V 700A 2300W Chassis Mount SP6 |
| Current - Collector Cutoff (Max) | 750µA | Current - Collector (Ic) (Max) | 700A |
| Configuration | Half Bridge |
