Home > Products > Connectors, Interconnects > Rectangular Connectors - Headers, Male Pins > MDF6-14DP-3.5DSA(05)

MDF6-14DP-3.5DSA(05)

MDF6-14DP-3.5DSA(05)
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy MDF6-14DP-3.5DSA(05) with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number MDF6-14DP-3.5DSA(05)
Manufacturer Hirose
Description CONN HDR 14POS 3.5MM
Lead Free Status / RoHS Status Lead free / RoHS Compliant
In Stock 78277 pcs
Reference Price
(In US Dollars)		100 pcs
$0.476

Submit a Request For Quotation on quantities greater than those displayed.

Target Price:(USD)
Quantity:
Total:
$0.476

Product parameter

Part Number MDF6-14DP-3.5DSA(05) Manufacturer Hirose
Description CONN HDR 14POS 3.5MM Lead Free Status / RoHS Status Lead free / RoHS Compliant
Quantity Available 78277 pcs Data sheet
Category Connectors, Interconnects Voltage Rating 300V
Termination Solder Style Board to Cable/Wire
Shrouding Shrouded - 4 Wall Series MDF6
Row Spacing - Mating 0.197" (5.00mm) Pitch - Mating 0.138" (3.50mm)
Packaging Bulk Overall Contact Length -
Other Names 547-0088-6-05 Operating Temperature -30°C ~ 85°C
Number of Rows 2 Number of Positions Loaded All
Number of Positions 14 Mounting Type Through Hole
Moisture Sensitivity Level (MSL) 1 (Unlimited) Material Flammability Rating UL94 V-0
Mated Stacking Heights - Manufacturer Standard Lead Time 16 Weeks
Lead Free Status / RoHS Status Lead free / RoHS Compliant Insulation Material Polyamide (PA), Nylon
Insulation Height 0.512" (13.00mm) Insulation Color White
Ingress Protection - Features -
Fastening Type Latch Holder Detailed Description Connector Header Through Hole 14 position 0.138" (3.50mm)
Current Rating - Contact Type Male Pin
Contact Shape Square Contact Material Brass
Contact Length - Post 0.138" (3.50mm) Contact Length - Mating 0.220" (5.59mm)
Contact Finish Thickness - Post - Contact Finish Thickness - Mating 39.4µin (1.00µm)
Contact Finish - Post - Contact Finish - Mating Tin-Copper
Connector Type Header Applications -
