MDF6-10DP-3.5DSA(06)
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy MDF6-10DP-3.5DSA(06) with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy MDF6-10DP-3.5DSA(06) with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | MDF6-10DP-3.5DSA(06) |
|---|---|
| Manufacturer | Hirose |
| Description | CONN HDR 10POS 3.5MM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | MDF6-10DP-3.5DSA(06) | Manufacturer | Hirose |
|---|---|---|---|
| Description | CONN HDR 10POS 3.5MM | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 4544 pcs | Data sheet | MDF6-xDP-3.5DSA(06) Drawing |
| Category | Connectors, Interconnects | Voltage Rating | 300V |
| Termination | Solder | Style | Board to Cable/Wire |
| Shrouding | Shrouded - 4 Wall | Series | MDF6 |
| Row Spacing - Mating | 0.197" (5.00mm) | Pitch - Mating | 0.138" (3.50mm) |
| Packaging | Bulk | Overall Contact Length | - |
| Other Names | 547-0086-0-06 | Operating Temperature | -30°C ~ 85°C |
| Number of Rows | 2 | Number of Positions Loaded | All |
| Number of Positions | 10 | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-0 |
| Mated Stacking Heights | - | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insulation Material | Polyamide (PA), Nylon | Insulation Height | 0.512" (13.00mm) |
| Insulation Color | White | Ingress Protection | - |
| Features | - | Fastening Type | Latch Holder |
| Detailed Description | Connector Header Through Hole 10 position 0.138" (3.50mm) | Current Rating | - |
| Contact Type | Male Pin | Contact Shape | Square |
| Contact Material | Brass | Contact Length - Post | 0.138" (3.50mm) |
| Contact Length - Mating | 0.220" (5.59mm) | Contact Finish Thickness - Post | 39.4µin (1.00µm) |
| Contact Finish Thickness - Mating | 8.00µin (0.203µm) | Contact Finish - Post | Tin-Copper |
| Contact Finish - Mating | Gold | Connector Type | Header |
| Applications | - |
