Home > Products > Transformers > Pulse Transformers > S558-5500-68

S558-5500-68

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy S558-5500-68 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	S558-5500-68
Manufacturer	Bel
Description	XFRMR MODULE LAN 10/100BT SMD
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 39482 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	25 pcs	50 pcs	100 pcs
Reference Price (In US Dollars)	$1.466	$1.187	$0.96	$0.899	$0.859

Product parameter
Data sheet

Product parameter

Part Number	S558-5500-68	Manufacturer	Bel
Description	XFRMR MODULE LAN 10/100BT SMD	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	39482 pcs	Data sheet	S558-5500-68 Drawing
Category	Transformers	Size / Dimension	0.690" L x 0.480" W (17.53mm x 12.20mm)
Series	*	Packaging	Cut Tape (CT)
Other Names	507-1956-1	Operating Temperature	-40°C ~ 85°C
Mounting Type	Surface Mount	Moisture Sensitivity Level (MSL)	2 (1 Year)
Manufacturer Standard Lead Time	15 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Height - Seated (Max)	0.230" (5.84mm)
