031-70335
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 031-70335 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 031-70335 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 031-70335 |
|---|---|
| Manufacturer | Amphenol Connex (Amphenol RF) |
| Description | CONN MINI BNC PLG STR 75 OHM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $5.453 | $4.958 | $4.834 | $4.462 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $4.214 | $3.842 | $3.594 | $3.297 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 031-70335 | Manufacturer | Amphenol Connex (Amphenol RF) |
|---|---|---|---|
| Description | CONN MINI BNC PLG STR 75 OHM | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 11256 pcs | Data sheet | 031-70335 Drawing |
| Category | Connectors, Interconnects | Shield Termination | Crimp |
| Series | - | Packaging | Bulk |
| Other Names | 31-70335 ARF2142 |
Operating Temperature | -40°C ~ 155°C |
| Number of Ports | 1 | Mounting Type | Free Hanging (In-Line) |
| Mounting Feature | - | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Mating Cycles | 500 | Manufacturer Standard Lead Time | 9 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insertion Loss | 0.1dB |
| Ingress Protection | - | Includes | 5 pcs - 1 Connector, 1 Contact, 1 Ferrule, 1 Sleeve, 1 Spacer |
| Impedance | 75 Ohm | Housing Color | Silver |
| Frequency - Max | 4GHz | Features | - |
| Fastening Type | Bayonet Lock | Dielectric Material | Polytetrafluoroethylene (PTFE) |
| Detailed Description | BNC, Mini Connector Plug, Male Pin 75 Ohm Free Hanging (In-Line) Crimp | Contact Termination | Crimp |
| Connector Type | Plug, Male Pin | Connector Style | BNC, Mini |
| Center Contact Plating | Gold | Center Contact Material | Brass |
| Cable Group | RG-174, 188, 188A, 316, LMR-100, M17/119-RG174 | Body Material | Phosphor Bronze |
| Body Finish | Nickel |
