8-323916-1
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 8-323916-1 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 8-323916-1 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 8-323916-1 |
|---|---|
| Manufacturer | Agastat Relays / TE Connectivity |
| Description | CONN RING CIRC 22-26AWG #8 CRIMP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $0.303 | $0.267 | $0.251 | $0.241 | $0.23 | |
| 250 pcs | 500 pcs | 1000 pcs | 2500 pcs | ||
| $0.209 | $0.188 | $0.167 | $0.152 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 8-323916-1 | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | CONN RING CIRC 22-26AWG #8 CRIMP | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 136372 pcs | Data sheet | 323916 Drawing |
| Category | Connectors, Interconnects | Wire Gauge | 22-26 AWG |
| Width - Outer Edges | 0.250" (6.35mm) | Thickness | 0.018" (0.46mm) |
| Termination | Crimp | Terminal Type | Circular |
| Stud/Tab Size | 8 Stud | Series | PIDG |
| Packaging | Bulk | Other Names | 83239161 |
| Mounting Type | Free Hanging (In-Line) | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Material - Insulation | Polyamide (PA), Nylon | Manufacturer Standard Lead Time | 14 Weeks |
| Length - Overall | 0.740" (18.80mm) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insulation Diameter | 0.050" ~ 0.082" (1.27mm ~ 2.08mm) | Insulation | Insulated |
| Features | Serrated Termination | Detailed Description | Ring Terminal Connector 8 Stud Circular 22-26 AWG Crimp |
| Contact Material | Copper | Contact Finish | Tin |
| Color | Yellow |
