1513472-5
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 1513472-5 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 1513472-5 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 1513472-5 |
|---|---|
| Manufacturer | Agastat Relays / TE Connectivity |
| Description | RF ANT 2.4GHZ/5.5GHZ MODULE CAB |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 100 pcs | |
|---|---|---|---|---|---|
| $2.499 | $2.231 | $2.008 | $1.829 | ||
| 250 pcs | 500 pcs | 1000 pcs | 2500 pcs | ||
| $1.651 | $1.481 | $1.249 | $1.187 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 1513472-5 | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | RF ANT 2.4GHZ/5.5GHZ MODULE CAB | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 31308 pcs | Data sheet | 1513472 Drawing1513472-5 Datasheet |
| Category | RF/IF and RFID | VSWR | 3 |
| Termination | Cable (360mm) - U.FL | Series | - |
| Return Loss | - | Power - Max | 10W |
| Packaging | Bulk | Other Names | A107425 |
| Number of Bands | 2 | Mounting Type | Panel Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 13 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Ingress Protection | - |
| Height (Max) | 0.394" (10.00mm) | Gain | 3dBi |
| Frequency Range | 2.4GHz ~ 2.483.5GHz, 5.15GHz ~ 5.875GHz | Frequency Group | UHF (2 GHz ~ 3 GHz), SHF (f > 4 GHz) |
| Frequency (Center/Band) | 2.4GHz, 5.5GHz | Features | - |
| Detailed Description | 2.4GHz, 5.5GHz Bluetooth, Wi-Fi, WLAN, Zigbee™ Module RF Antenna 2.4GHz ~ 2.483.5GHz, 5.15GHz ~ 5.875GHz 3dBi Cable (360mm) - U.FL Panel Mount | Applications | Bluetooth, Wi-Fi, WLAN, Zigbee™ |
| Antenna Type | Module |
