1274566-1
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 1274566-1 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 1274566-1 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 1274566-1 |
|---|---|
| Manufacturer | Agastat Relays / TE Connectivity |
| Description | CONN MINI BNC PLG R/A 75 OHM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 400 pcs | ||||
|---|---|---|---|---|---|
| $5.082 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | 1274566-1 | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | CONN MINI BNC PLG R/A 75 OHM | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 6734 pcs | Data sheet | 1274566 |
| Category | Connectors, Interconnects | Voltage Rating | 300V |
| Shield Termination | Crimp | Series | - |
| Packaging | Tray | Other Names | A30533 |
| Operating Temperature | -40°C ~ 85°C | Number of Ports | 1 |
| Mounting Type | Free Hanging (In-Line), Right Angle | Mounting Feature | - |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Mating Cycles | 500 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insertion Loss | - |
| Ingress Protection | - | Includes | 3 pcs - 1 Connector, 1 End Cap, 1 Ferrule |
| Impedance | 75 Ohm | Housing Color | Silver |
| Frequency - Max | 2GHz | Features | - |
| Fastening Type | Bayonet Lock | Dielectric Material | Polytetrafluoroethylene (PTFE) |
| Detailed Description | BNC, Mini Connector Plug, Male Pin 75 Ohm Free Hanging (In-Line), Right Angle Solder | Contact Termination | Solder |
| Connector Type | Plug, Male Pin | Connector Style | BNC, Mini |
| Center Contact Plating | Gold | Center Contact Material | Brass |
| Cable Group | AT&T 735A | Body Material | Brass |
| Body Finish | Nickel |
