CHG-2020-001010-KCP
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy CHG-2020-001010-KCP with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy CHG-2020-001010-KCP with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | CHG-2020-001010-KCP |
|---|---|
| Manufacturer | 3M |
| Description | CONN RECEPT IDC 20POS 28-26 AWG |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $2.455 | $2.353 | $2.149 | $2.046 | $1.944 | |
| 250 pcs | 500 pcs | 1000 pcs | 2500 pcs | ||
| $1.739 | $1.637 | $1.432 | $1.361 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | CHG-2020-001010-KCP | Manufacturer | 3M |
|---|---|---|---|
| Description | CONN RECEPT IDC 20POS 28-26 AWG | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 25008 pcs | Data sheet | Interconnect CatalogCHG Series SpecificationCHG-20 Series Datasheet |
| Category | Connectors, Interconnects | Wire Type | Discrete or Ribbon Cable |
| Wire Gauge | 26-28 AWG | Series | CHG |
| Row Spacing | 0.100" (2.54mm) | Pitch | 0.100" (2.54mm) |
| Packaging | Bulk | Other Names | 00054007664390 05400766439 3M9096 5400766439 54007664390 80610421473 CHG-2020-001010-KCP-ND CHG2020001010KCP |
| Number of Rows | 2 | Number of Positions | 20 |
| Mounting Type | Free Hanging (In-Line) | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 6 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Features | Closed End | Fastening Type | - |
| Detailed Description | 20 Position Rectangular Receptacle Connector IDC Gold 26-28 AWG | Contact Type | Female Socket |
| Contact Finish Thickness | 30.0µin (0.76µm) | Contact Finish | Gold |
| Connector Type | Receptacle | Color | Gray |
| Cable Termination | IDC |
