Home > Products > Connectors, Interconnects > Rectangular Connectors - Free Hanging, Panel Mount > CHG-2016-001010-KCP

CHG-2016-001010-KCP

CHG-2016-001010-KCP

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy CHG-2016-001010-KCP with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	CHG-2016-001010-KCP
Manufacturer	3M
Description	CONN RECEPT IDC 16POS 28-26 AWG
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 19389 pcs
Reference Price (In US Dollars)	300 pcs
Reference Price (In US Dollars)	$1.626

Product parameter
Data sheet

Product parameter

Part Number	CHG-2016-001010-KCP	Manufacturer	3M
Description	CONN RECEPT IDC 16POS 28-26 AWG	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	19389 pcs	Data sheet	Interconnect Catalog CHG Series Specification CHG-20 Series Datasheet
Category	Connectors, Interconnects	Wire Type	Discrete or Ribbon Cable
Wire Gauge	26-28 AWG	Series	CHG
Row Spacing	0.100" (2.54mm)	Pitch	0.100" (2.54mm)
Packaging	Bulk	Other Names	00051138442248 05113844224 3M9058 5113844224 51138442248 7010319315 80610815948 CHG2016001010KCP
Number of Rows	2	Number of Positions	16
Mounting Type	Free Hanging (In-Line)	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Manufacturer Standard Lead Time	6 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Features	Closed End	Fastening Type	-
Detailed Description	16 Position Rectangular Receptacle Connector IDC Gold 26-28 AWG	Contact Type	Female Socket
Contact Finish Thickness	30.0µin (0.76µm)	Contact Finish	Gold
Connector Type	Receptacle	Color	Gray
Cable Termination	IDC
