CHG-2016-J01010-KCP
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy CHG-2016-J01010-KCP with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy CHG-2016-J01010-KCP with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | CHG-2016-J01010-KCP |
|---|---|
| Manufacturer | 3M |
| Description | CONN RECEPT IDC 16POS 28-26 AWG |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $2.231 | $2.142 | $1.963 | $1.874 | $1.785 | |
| 250 pcs | 500 pcs | 1000 pcs | 2500 pcs | ||
| $1.562 | $1.517 | $1.294 | $1.205 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | CHG-2016-J01010-KCP | Manufacturer | 3M |
|---|---|---|---|
| Description | CONN RECEPT IDC 16POS 28-26 AWG | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 28366 pcs | Data sheet | CHG-20 Series, Polarized DatasheetInterconnect CatalogCHG Series Specification |
| Category | Connectors, Interconnects | Wire Type | Discrete or Ribbon Cable |
| Wire Gauge | 26-28 AWG | Series | CHG |
| Row Spacing | 0.100" (2.54mm) | Pitch | 0.100" (2.54mm) |
| Packaging | Bulk | Other Names | 00054007668305 05400766830 3M9094 5400766830 54007668305 7010396437 80610425383 CHG-2016-J01010-KCP-ND CHG2016J01010KCP |
| Number of Rows | 2 | Number of Positions | 16 |
| Mounting Type | Free Hanging (In-Line) | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 6 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Features | Closed End, Polarizing Key | Fastening Type | - |
| Detailed Description | 16 Position Rectangular Receptacle Connector IDC Gold 26-28 AWG | Contact Type | Female Socket |
| Contact Finish Thickness | 30.0µin (0.76µm) | Contact Finish | Gold |
| Connector Type | Receptacle | Color | Gray |
| Cable Termination | IDC |
