PI3749-00-EVAL1
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy PI3749-00-EVAL1 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy PI3749-00-EVAL1 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | PI3749-00-EVAL1 |
|---|---|
| Manufacturer | Vicor |
| Description | PICOR COOL-POWER EVAL BD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | ||||
|---|---|---|---|---|---|
| $13.989 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | PI3749-00-EVAL1 | Manufacturer | Vicor |
|---|---|---|---|
| Description | PICOR COOL-POWER EVAL BD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 2624 pcs | Data sheet | PI3749-x0 Datasheet |
| Category | Development Boards, Kits, Programmers | Voltage - Output | 12 V ~ 34 V |
| Voltage - Input | 16 V ~ 34 V | Utilized IC / Part | PI3749-00 |
| Supplied Contents | Board(s) | Series | Cool-Power® |
| Regulator Topology | Buck-Boost | Power - Output | 180W |
| Outputs and Type | 1, Non-Isolated | Other Names | 1102-5405 |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 16 Weeks |
| Main Purpose | DC/DC, Step Up or Down | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Frequency - Switching | 800kHz | Detailed Description | PI3749-00 Cool-Power® DC/DC, Step Up or Down 1, Non-Isolated Outputs Evaluation Board |
| Current - Output | 7.5A | Board Type | Fully Populated |
