F-215U
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy F-215U with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy F-215U with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | F-215U |
|---|---|
| Manufacturer | Triad Magnetics |
| Description | POWER XFMR CHASSIS MOUNT W/LUGS |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $14.939 | $14.44 | $13.444 | $12.448 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | F-215U | Manufacturer | Triad Magnetics |
|---|---|---|---|
| Description | POWER XFMR CHASSIS MOUNT W/LUGS | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 2585 pcs | Data sheet | F-215U Datasheet |
| Category | Transformers | Weight | 6.1 lbs (2.8kg) |
| Voltage - Secondary (Full Load) | Parallel 24V, Series 48V | Voltage - Primary | 115V, 230V |
| Voltage - Isolation | 1500Vrms | Type | Laminated Core |
| Termination Style | Solder Lug | Size / Dimension | 87.30mm L x 98.43mm W |
| Series | Control Transformers | Secondary Winding(s) | Dual |
| Primary Winding(s) | Single | Power - Max | 192 VA |
| Other Names | 237-1934 | Mounting Type | Chassis Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 16 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Height - Seated (Max) | 106.35mm |
| Current - Output (Max) | Parallel 8A, Series 4A | Center Tap | No |
