F-214U
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy F-214U with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy F-214U with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | F-214U |
|---|---|
| Manufacturer | Triad Magnetics |
| Description | POWER XFMR CHASSIS MOUNT W/LUGS |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $12.169 | $10.736 | $10.378 | $9.305 | $8.947 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | F-214U | Manufacturer | Triad Magnetics |
|---|---|---|---|
| Description | POWER XFMR CHASSIS MOUNT W/LUGS | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 3870 pcs | Data sheet | F-214U Datasheet |
| Category | Transformers | Weight | 3.3 lbs (1.5kg) |
| Voltage - Secondary (Full Load) | Parallel 24V, Series 48V | Voltage - Primary | 115V, 230V |
| Voltage - Isolation | 1500Vrms | Type | Laminated Core |
| Termination Style | Solder Lug | Size / Dimension | 80.95mm L x 71.42mm W |
| Series | Control Transformers | Secondary Winding(s) | Dual |
| Primary Winding(s) | Single | Power - Max | 96 VA |
| Other Names | 237-1933 | Mounting Type | Chassis Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 16 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Height - Seated (Max) | 86.51mm |
| Current - Output (Max) | Parallel 4A, Series 2A | Center Tap | No |
