TSM60NB600CP ROG
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy TSM60NB600CP ROG with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy TSM60NB600CP ROG with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | TSM60NB600CP ROG |
|---|---|
| Manufacturer | TSC (Taiwan Semiconductor) |
| Description | MOSFET N-CHANNEL 600V 7A TO252 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 2500 pcs | ||||
|---|---|---|---|---|---|
| $0.236 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | TSM60NB600CP ROG | Manufacturer | TSC (Taiwan Semiconductor) |
|---|---|---|---|
| Description | MOSFET N-CHANNEL 600V 7A TO252 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 84909 pcs | Data sheet | TSM60NB600CP |
| Category | Discrete Semiconductor Products | Vgs(th) (Max) @ Id | 4V @ 250µA |
| Vgs (Max) | ±30V | Technology | MOSFET (Metal Oxide) |
| Supplier Device Package | TO-252, (D-Pak) | Series | - |
| Rds On (Max) @ Id, Vgs | 600 mOhm @ 2.1A, 10V | Power Dissipation (Max) | 63W (Tc) |
| Packaging | Tape & Reel (TR) | Package / Case | TO-252-3, DPak (2 Leads + Tab), SC-63 |
| Other Names | TSM60NB600CP ROGTR TSM60NB600CP ROGTR-ND TSM60NB600CPROGTR |
Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 3 (168 Hours) |
| Manufacturer Standard Lead Time | 36 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Input Capacitance (Ciss) (Max) @ Vds | 516pF @ 100V | Gate Charge (Qg) (Max) @ Vgs | 13nC @ 10V |
| FET Type | N-Channel | FET Feature | - |
| Drive Voltage (Max Rds On, Min Rds On) | 10V | Drain to Source Voltage (Vdss) | 600V |
| Detailed Description | N-Channel 600V 7A (Tc) 63W (Tc) Surface Mount TO-252, (D-Pak) | Current - Continuous Drain (Id) @ 25°C | 7A (Tc) |
