Home > Products > Integrated Circuits (ICs) > Interface - Analog Switches, Multiplexers, Demulti > STG3684ADTR

STG3684ADTR

STG3684ADTR
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy STG3684ADTR with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number STG3684ADTR
Manufacturer STMicroelectronics
Description IC SWITCH DUAL SPDT 10UFDFN
Lead Free Status / RoHS Status Lead free / RoHS Compliant
In Stock 102670 pcs
Reference Price
(In US Dollars)		3000 pcs
$0.367

Submit a Request For Quotation on quantities greater than those displayed.

Target Price:(USD)
Quantity:
Total:
$0.367

Product parameter

Part Number STG3684ADTR Manufacturer STMicroelectronics
Description IC SWITCH DUAL SPDT 10UFDFN Lead Free Status / RoHS Status Lead free / RoHS Compliant
Quantity Available 102670 pcs Data sheet STG3684A
Category Integrated Circuits (ICs) Voltage - Supply, Single (V+) 1.65 V ~ 4.3 V
Voltage - Supply, Dual (V±) - Switch Time (Ton, Toff) (Max) 55ns, 30ns
Switch Circuit SPDT Supplier Device Package 10-DFN (2.3x2.0)
Series - Packaging Tape & Reel (TR)
Package / Case 10-UFDFN Exposed Pad Operating Temperature -40°C ~ 85°C (TA)
On-State Resistance (Max) 500 mOhm Number of Circuits 2
Multiplexer/Demultiplexer Circuit 2:1 Moisture Sensitivity Level (MSL) 3 (168 Hours)
Lead Free Status / RoHS Status Lead free / RoHS Compliant Detailed Description 2 Circuit IC Switch 2:1 500 mOhm 10-DFN (2.3x2.0)
Current - Leakage (IS(off)) (Max) 20nA Crosstalk -72dB @ 100kHz
Charge Injection 49pC Channel-to-Channel Matching (ΔRon) 100 mOhm
Channel Capacitance (CS(off), CD(off)) 5pF Base Part Number STG3684
-3db Bandwidth 55MHz
