PA3144HL
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy PA3144HL with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy PA3144HL with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | PA3144HL |
|---|---|
| Manufacturer | Pulse Electronics Corporation |
| Description | INDUCT ARRAY 4 COIL SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | PA3144HL | Manufacturer | Pulse Electronics Corporation |
|---|---|---|---|
| Description | INDUCT ARRAY 4 COIL SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 5274 pcs | Data sheet | PA314xHL Series Datasheet |
| Category | Inductors, Coils, Chokes | Tolerance | - |
| Size / Dimension | 1.417" L x 0.433" W (36.00mm x 11.00mm) | Shielding | Shielded |
| Series | PA314HL | Ratings | - |
| Packaging | Tray | Package / Case | 8-SMD, No Lead |
| Other Names | 553-2956 | Operating Temperature | -40°C ~ 130°C |
| Number of Coils | 4 | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Height | 0.315" (8.00mm) | Detailed Description | Shielded 4 Coil Inductor Array 8-SMD, No Lead |
| DC Resistance (DCR) - Series | - | DC Resistance (DCR) - Parallel | - |
