P8205
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy P8205 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy P8205 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | P8205 |
|---|---|
| Manufacturer | Pulse Electronics Corporation |
| Description | CURR SENSE XFMR 1:50 SMD |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | P8205 | Manufacturer | Pulse Electronics Corporation |
|---|---|---|---|
| Description | CURR SENSE XFMR 1:50 SMD | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Quantity Available | 4901 pcs | Data sheet | P820x Series |
| Category | Transformers | Type | Invasive |
| Turns Ratio - Primary:Secondary | 1:50 | Size / Dimension | 0.284" L x 0.330" W (7.21mm x 8.38mm) |
| Series | P820X | Ratings | - |
| Packaging | Tray | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Height - Seated (Max) | 0.217" (5.50mm) | Frequency Range | 50kHz ~ 1MHz |
| Energy Time (E.T.) | - | Detailed Description | 1:50 Current Sense Transformer 50kHz ~ 1MHz 6 mOhm Surface Mount |
| DC Resistance (DCR) | 6 mOhm | Current Ratio | - |
