P0583NL
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy P0583NL with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy P0583NL with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | P0583NL |
|---|---|
| Manufacturer | Pulse Electronics Corporation |
| Description | CURR SENSE XFMR 50:1:1 36A T/H |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 80 pcs | 160 pcs |
|---|---|---|---|---|---|
| $1.207 | $0.979 | $0.792 | $0.742 | $0.708 | |
| 320 pcs | 560 pcs | 1040 pcs | 5040 pcs | ||
| $0.687 | $0.667 | $0.646 | $0.594 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | P0583NL | Manufacturer | Pulse Electronics Corporation |
|---|---|---|---|
| Description | CURR SENSE XFMR 50:1:1 36A T/H | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 58116 pcs | Data sheet | P058x Series THT Current Sense Xfrmrs |
| Category | Transformers | Weight | 0.011 lb (4.99g) |
| Type | Invasive | Turns Ratio - Primary:Secondary | 50:1:1 |
| Termination Style | PC Pin | Size / Dimension | 0.810" L x 0.580" W (20.57mm x 14.73mm) |
| Series | THT | Ratings | - |
| Packaging | Tray | Other Names | 553-2660 P0583NL-ND |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 13 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance | 5mH | Height - Seated (Max) | 0.750" (19.05mm) |
| Frequency Range | 50kHz ~ 500kHz | Energy Time (E.T.) | - |
| Detailed Description | 36A 50:1:1 Current Sense Transformer 50kHz ~ 500kHz 700 mOhm Primary, 1.7 mOhm Secondary 5mH Through Hole | DC Resistance (DCR) | 700 mOhm Primary, 1.7 mOhm Secondary |
| Current Ratio | - | Current Rating | 36A |
