HX5224CNL
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy HX5224CNL with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy HX5224CNL with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | HX5224CNL |
|---|---|
| Manufacturer | Pulse Electronics Corporation |
| Description | PULSE XFMR 1 CT:1CT TX/RX 350UH |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $4.431 | $3.273 | $3.021 | $2.921 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $2.84 | $2.80 | $2.77 | $2.719 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | HX5224CNL | Manufacturer | Pulse Electronics Corporation |
|---|---|---|---|
| Description | PULSE XFMR 1 CT:1CT TX/RX 350UH | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 13265 pcs | Data sheet | HX5224CNL Datasheet |
| Category | Transformers | Weight | - |
| Turns Ratio - Primary:Secondary | 1CT:1CT Transmitter, 1CT:1CT Receiver | Transformer Type | LAN 10/100/1000 Base-T |
| Size / Dimension | 0.728" L x 0.604" W (18.50mm x 15.34mm) | Series | - |
| Other Names | 553-3524 HX5224CNL-ND |
Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Inductance | 350µH |
| Height - Seated (Max) | 0.385" (9.77mm) | Energy Time (E.T.) | - |
