HX5149NL
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy HX5149NL with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy HX5149NL with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | HX5149NL |
|---|---|
| Manufacturer | Pulse Electronics Corporation |
| Description | PULSE XFMR 1:1 360UH |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $2.625 | $1.995 | $1.943 | $1.785 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $1.68 | $1.628 | $1.575 | $1.523 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | HX5149NL | Manufacturer | Pulse Electronics Corporation |
|---|---|---|---|
| Description | PULSE XFMR 1:1 360UH | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 19822 pcs | Data sheet | H5138NL, H/HX5149NL Datasheet |
| Category | Transformers | Turns Ratio - Primary:Secondary | 1:1 |
| Transformer Type | LAN 10/100/1000 Base-T | Size / Dimension | 0.700" L x 0.390" W (17.78mm x 9.91mm) |
| Series | - | Packaging | Tube |
| Other Names | 553-2810-5 | Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 13 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance | 360µH | Height - Seated (Max) | 0.126" (3.20mm) |
